Aluminum Column Beam Honeycomb Panel

Type:	Curtain Walls or Suspended Ceiling
Place of Origin:	Guangdong, China
Brand Name:	Bahe
Key Words:	aluminum honeycomb panel, aluminum composite panel
Materials:	aluminum alloy
Thickness:	10 ~ 100 mm
Width:	≤ 2200 mm
Length:	≤ 6000 mm
Color:	RAL color or customized
Surface treatment:	PVDF coated, polyester powder coated, hermal transfer
Certification:	CE, SGS, ISO 9001:2000
M.O.Q	1 square meter
Price:	FOB price
Free Sample:	Yes
Guarantee:	10 Years
Package:	plastic film, bubble inside, cartoon outside, wooden support
Delivery:	15~20 working days, or depend on quantity

SEND INQUIRY

You can make an inquiry about this product.
Your e-mail will not be leaked.

PRODUCT DETAIL

Column aluminum Honeycomb Panel has advantages as high strength, light weight, well flatness, fire proof, soundproof, heat insulation, excellent weather resistance and easy to clean.

Advantages

High strength, good stiffness, light weight, good surface smoothness, good fire resistance, flame retardant B1 grade composite;
Good sound insulation, air insulation 25dB;
Good thermal insulation effect: thermal conductivity 0.1613W / (m · K);
Weather resistance, self-cleaning ability, and good temperature resistance

Product Specification

Specification	overall thickness: 10 ~ 100 mm
	width ≤ 2200 mm
	length ≤ 6000 mm
Face Sheet	Materials: high grade aluminum alloy ( 3003, 5005, 5754, AA 1100 )
Face Sheet	Thickness ≥ 1.0 mm ( curtain wall standard ) or ≥ 0.7 mm ( non-standard )
Core	Materials: high grade anti-corrosive aluminum honeycomb core
Core	Aluminum foils’ thickness: 6 mm
Bottom Sheet	Material: high grade aluminum alloy ( 3003, 5005, 5754 )
Bottom Sheet	thickness ≥ 0.7 mm ( standard ) or ≥ 0.5 mm ( non-standard )
Binder	Two-component high-temperature curing polyurethane adhesive of fuller/ hot melt adhesive membrane.
Treatment	PVDF coated, polyester powder coated, hermal transfer
Color	RAL color or customized
Density	5.0 ~ 7.5 KG/ m2
Certificated	CE, SGS, ISO 9001:2000
